| Server Configuration and Availability |
|---|
| Vendor | Sun Microsystems Inc. |
| Hardware Available | March 1998 |
| Software Available | May 1996 |
| Date Tested | February 1998 |
| SFS License Number | 6 |
| Licensee Locations | Palo Alto, CA |
| CPU, Memory and Power |
|---|
| Model Name | Sun Enterprise 4002 |
| Processor | 336 MHz UltraSPARC II |
| # of Processors | 12 |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 4MB(I+D) off chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 6 GB |
| NVRAM Size | N/A |
| NVRAM Type | N/A |
| NVRAM Description | N/A |
| Server Software |
|---|
| OS Name and Version | Solaris 2.5.1 |
| Other Software | N/A |
| File System | UFS |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 479 |
| Fileset Size | 195.8 GB |
|
| Network Subsystem |
|---|
| Network Type | 100Mbit Sun FastEthernet |
| Network Controller Desc. | SunSwift 100baseT f/w SCSI SBus Adapter |
| Number Networks | 6 (N1-N6) |
| Number Network Controllers | 6 |
| Protocol Type | UDP |
| Switch Type | 6 SunSwitch |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 9 |
| Number of Disks | 244 |
| Number of Filesystems | 240 (F1-F240) |
| File System Creation Ops | default |
| File System Config | default |
| Disk Controller | On-board SCSI-2 |
| # of Controller Type | 1 |
| Number of Disks | 4 |
| Disk Type | 2GB 7200rpm |
| File Systems on Disks | OS, swap |
| Special Config Notes | |
| Disk Controller | FC SBUS Adapter (FC25/S)/FC Optical Module (FC25/OM) |
| # of Controller Type | 8 |
| Number of Disks | 240 |
| Disk Type | 2GB 7200rpm |
| File Systems on Disks | F1-30,F31-F60,F61-F90, F91-F120,F121-F150,F151-F180, F181-F210,F211-F240 |
| Special Config Notes | SPARCstorage Array 102 each w/ 30 drives |
|
| Testbed Configuration |
|---|
| LG # | LG Type | Network | Target File Systems | Notes |
| 1/2/3 | LG1 | N1 | F1,..,F235,..,F223/F2,..,F236,..,F224/F3,..,F237,..,F225 | |
| 4/5/6 | LG1 | N2 | F4,..,F238,..,F226/F5,..,F239,..,F227/F6,..,F240,..,F228 | |
| 7/8/9 | LG1 | N3 | F7,..,F1,..,F229/F8,..,F2,..,F230/F9,..,F3,..,F231 | |
| 10/11/12 | LG1 | N4 | F10,..,F4,..,F232/F11,..,F5,..,F233/F12,..,F6,..,F234 | |
| 13/14/15 | LG1 | N5 | F13,..,F7,..,F235/F14,..,F8,..,F236/F15,..,F9,..,F237 | |
| 16/17/18 | LG1 | N6 | F16,..,F10,..,F238/F17,..,F11,..,F239/F18,..,F12,..,F240 | |
