Hewlett Packard Enterprise Synergy 660 Gen10 Compute Module SPECpower_ssj2008 = 10,754 overall ssj_ops/watt
Test Sponsor: Hewlett Packard Enterprise SPEC License #: 3 Test Method: Multi Node
Tested By: Hewlett Packard Enterprise Test Location: Houston, TX, USA Test Date: Mar 10, 2019
Hardware Availability: Apr-2019 Software Availability: Mar-2019 Publication: Apr 2, 2019
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Average Active Power (W) Minimum Ambient Temperature (°C)
Calibration 1 2,980 22.5
Calibration 2 3,012 22.5
Calibration 3 3,013 22.6
100% 3,004 22.6
90% 2,722 22.6
80% 2,378 22.5
70% 2,023 22.4
60% 1,758 22.4
50% 1,536 22.4
40% 1,337 22.2
30% 1,154 22.3
20% 981 22.2
10% 828 22.2
Active Idle 421 22.2
Graph of power and temperature
Measurement Devices
Power Analyzer pwr1
Hardware Vendor: Yokogawa
Model: WT210
Serial Number: 91GB53024
Connectivity: GPIB vi NI GPIB-USB-HS
Input Connection: Default
Metrology Institute: NIST
Accredited by: TRANSCAT
Calibration Label: 5-EM5Y4-80-1
Date of Calibration: 21-Jun-2018
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
PTDaemon Version: 1.8.1-260d064e-20161220
Setup Description: SUT Power Supply 5
Power Analyzer pwr2
Hardware Vendor: Yokogawa
Model: WT210
Serial Number: 91GB47168
Connectivity: GPIB vi NI GPIB-USB-HS
Input Connection: Default
Metrology Institute: NIST
Accredited by: TRANSCAT
Calibration Label: 5-EM5Y4-60-1
Date of Calibration: 21-Jun-2018
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
PTDaemon Version: 1.8.1-260d064e-20161220
Setup Description: SUT Power Supply 3
Power Analyzer pwr3
Hardware Vendor: Yokogawa
Model: WT210
Serial Number: 91GC21887
Connectivity: GPIB vi NI GPIB-USB-HS
Input Connection: Default
Metrology Institute: NIST
Accredited by: TRANSCAT
Calibration Label: 5-EM5Y4-20-1
Date of Calibration: 21-Jun-2018
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
PTDaemon Version: 1.8.1-260d064e-20161220
Setup Description: SUT Power Supplies 1 and 2
Temperature Sensor temp1
Hardware Vendor: Digi International Inc.
Model: Watchport/H
Driver Version: 5.70.105.0
Connectivity: USB
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
Setup Description: 5 mm in front of SUT main intake
Notes
None
Power Details for Device pwr1
Target Load Voltage (V) Current (A) Avg Power Factor Avg Active Power (W) Power Measurement Uncertainty (%)
Avg Range Avg Range
Calibration 1 215 300.0 3.44 5.0 0.990 734 0.4%
Calibration 2 215 300.0 3.47 5.0 0.990 738 0.4%
Calibration 3 215 300.0 3.45 5.0 0.990 736 0.4%
100% 215 300.0 3.44 5.0 0.990 733 0.4%
90% 215 300.0 3.16 5.0 0.988 674 0.4%
80% 216 300.0 2.79 5.0 0.985 593 0.4%
70% 216 300.0 2.37 5.0 0.979 502 0.5%
60% 216 300.0 1.99 5.0 0.969 416 0.6%
50% 216 300.0 1.65 2.0 0.957 342 0.4%
40% 216 300.0 1.40 2.0 0.941 285 0.4%
30% 216 300.0 1.18 2.0 0.894 227 0.5%
20% 216 300.0 1.06 2.0 0.858 196 0.6%
10% 216 300.0 0.989 2.0 0.851 182 0.6%
Active Idle 216 300.0 0.584 1.0 0.613 77.6 0.8%
Power details for pwr1
Power Details for Device pwr2
Target Load Voltage (V) Current (A) Avg Power Factor Avg Active Power (W) Power Measurement Uncertainty (%)
Avg Range Avg Range
Calibration 1 215 300.0 7.09 10.0 0.992 1,512 0.4%
Calibration 2 215 300.0 7.19 10.0 0.993 1,532 0.4%
Calibration 3 215 300.0 7.20 10.0 0.993 1,535 0.4%
100% 215 300.0 7.18 10.0 0.993 1,531 0.4%
90% 215 300.0 6.50 10.0 0.991 1,384 0.4%
80% 215 300.0 5.70 10.0 0.989 1,213 0.4%
70% 215 300.0 4.89 10.0 0.984 1,037 0.5%
60% 216 300.0 4.33 10.0 0.980 915 0.5%
50% 216 300.0 3.87 5.0 0.974 812 0.4%
40% 216 300.0 3.45 5.0 0.968 721 0.4%
30% 216 300.0 3.12 5.0 0.959 645 0.4%
20% 216 300.0 2.76 5.0 0.944 563 0.5%
10% 216 300.0 2.34 5.0 0.914 462 0.6%
Active Idle 216 300.0 1.44 2.0 0.793 247 0.5%
Power details for pwr2
Power Details for Device pwr3
Target Load Voltage (V) Current (A) Avg Power Factor Avg Active Power (W) Power Measurement Uncertainty (%)
Avg Range Avg Range
Calibration 1 213 300.0 3.49 5.0 0.989 734 0.4%
Calibration 2 212 300.0 3.53 5.0 0.989 742 0.4%
Calibration 3 213 300.0 3.53 5.0 0.989 743 0.4%
100% 213 300.0 3.52 5.0 0.989 740 0.4%
90% 213 300.0 3.16 5.0 0.987 665 0.4%
80% 213 300.0 2.73 5.0 0.982 571 0.5%
70% 213 300.0 2.32 5.0 0.975 483 0.5%
60% 213 300.0 2.07 5.0 0.968 427 0.6%
50% 213 300.0 1.86 2.0 0.961 381 0.4%
40% 213 300.0 1.63 2.0 0.950 331 0.4%
30% 213 300.0 1.41 2.0 0.933 281 0.4%
20% 213 300.0 1.19 2.0 0.877 222 0.5%
10% 213 300.0 1.03 1.0 0.835 184 0.4%
Active Idle 214 300.0 0.653 1.0 0.692 96.5 0.7%
Power details for pwr3
