SPECpower_ssj2008 Aggregate Performance Report

SPECpower_ssj2008

Aggregate Performance Report

ASUSTeK Computer Inc. RS720Q-E9-RS8			ssj_ops@100% = 19,257,841 ssj_ops@100% per Host = 4,814,460 ssj_ops@100% per JVM = 85,973
Test Sponsor:	ASUSTeK Computer Inc.	SPEC License #:	9016	Test Method:	Multi Node
Tested By:	ASUSTeK Computer Inc.	Test Location:	Taipei, Taiwan.	Test Date:	Jan 10, 2019
Hardware Availability:	Jan-2019	Software Availability:	Aug-2018	Publication:	May 10, 2019
System Source:	Single Supplier	System Designation:	Server	Power Provisioning:	Line-powered

# of Nodes	# of Chips	# of Cores	# of Threads	Total RAM (GB)	# of OS Images	# of JVM Instances
4	8	224	448	768	4	224

Shared Hardware
Enclosure:	None
Form Factor:	2U
Power Supply Quantity and Rating (W):	1 x 2200
Power Supply Details:	Delta Electronics, INC. DPS-2200AB-2 E
Network Switch:	D-Link DGS-105
Network Switch Details:	5-Port Giga LAN
KVM Switch:	None
KVM Switch Details:	N/A
Other Hardware:	None
Comment:	Network switch did not measure for power

Hardware per Node
Hardware Vendor:	ASUSTeK Computer Inc.
Model:	RS720Q-E9-RS8
Form Factor:	2U
CPU Name:	Intel Xeon Platinum 8176M
CPU Characteristics:	28 Core, 2.10GHz, 38.5MB L3 Cache
CPU Frequency (MHz):	2100
CPU(s) Enabled:	56 cores, 2 chips, 28 cores/chip
Hardware Threads:	112 (2 / core)
CPU(s) Orderable:	1,2 chips
Primary Cache:	32 KB I + 32 KB D on chip per core
Secondary Cache:	1 MB I+D on chip per core
Tertiary Cache:	39424 KB I+D on chip per chip
Other Cache:	None
Memory Amount (GB):	192
# and size of DIMM:	12 x 16 GB
Memory Details:	12 x 16GB 2Rx8 PC4-2666V ECC RDIMM; slots DIMM_A1, DIMMM_B1, DIMMM_C1, DIMMM_D1, DIMMM_E1, DIMMM_F1, DIMMM_G1, DIMMM_H1, DIMMM_J1, DIMMM_K1, DIMMM_L1, DIMMM_M1
Power Supply Quantity and Rating (W):	None
Power Supply Details:	Shared
Disk Drive:	1 x 960GB Intel DC S3520 SATA 2.5 SSD
Disk Controller:	Marvell 9230 SATA controller
# and type of Network Interface Cards (NICs) Installed:	1 x Dual-port Intel I350 Gigabit Ethernet controller
NICs Enabled in Firmware / OS / Connected:	2/1/1
Network Speed (Mbit):	1000
Keyboard:	None
Mouse:	None
Monitor:	None
Optical Drives:	No
Other Hardware:	None

Software per Node
Power Management:	Enabled
Operating System (OS):	Microsoft Windows Server 2012 R2 Datacenter
OS Version:	Version 6.3 (Build 9600)
Filesystem:	NTFS
JVM Vendor:	Oracle Corporation
JVM Version:	Oracle Java HotSpot(TM) 64-Bit Server VM (build 24.80-b11, mixed mode), version 1.7.0_80
JVM Command-line Options:	-Xmx1550m -Xms1550m -Xmn1300m -XX:SurvivorRatio=1 -XX:TargetSurvivorRatio=99 -XX:ParallelGCThreads=2 -XX:AllocatePrefetchDistance=256 -XX:AllocatePrefetchLines=4 -XX:LoopUnrollLimit=45 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15 -XX:InlineSmallCode=3900 -XX:MaxInlineSize=270 -XX:FreqInlineSize=2500 -XX:+UseLargePages -XX:+UseParalleOldGC -XX:+AggressiveOpts
JVM Affinity:	start /NODE [0,2,] /AFFINITY [3, C, 30, C0, C000, 30000, C0000, 30000000, C0000000, 300000000, C00000000, C0000000000, 300000000000, C00000000000]; start /NODE [1,3] /AFFINITY [3, C, 30, 3000, C000, 30000, C0000, 30000000, C0000000, 300000000, 30000000000, C0000000000, 300000000000, C00000000000]
JVM Instances:	56
JVM Initial Heap (MB):	1550
JVM Maximum Heap (MB):	1550
JVM Address Bits:	64
Boot Firmware Version:	3501
Management Firmware Version:	1.12.8
Workload Version:	SSJ 1.2.10
Director Location:	Controller
Other Software:	MS-KB4343891

See SUT Notes

Using the Local Security Settings Console.
Lock pages in Memory was Enabled for the User Running the Benchmark.
Balanced mode.
Benchmark was started via Windows Remote Desktop Connection.
Hard Disk set to Turn Off After 1 Minute.
Display Set to Turn Off After 1 Minute.
Minmum Processor State 0%.
Maximum Processor State:99%.
System Cooling Poloicy:Passive.
PCIE Power Management Maximum Power Saving.
Applied protection against speculative execution as explained in https://support.microsoft.com/en-us/help/4072698/windows-server-guidance-to-protect-against-the-speculative-execution (Last Updated: Feb 28, 2018).
Yes:The test sponsor attests, as of date of publication, the CVE-2017-5754(Meltdown) is mitigated in the system as tested and documented.
Yes:The test sponsor attests, as of date of publication, the CVE-2017-5753(Spectre varint 1) is mitigated in the system as tested and documented.
Yes:The test sponsor attests, as of date of publication, the CVE-2017-5715(Spectre variant 2) is mitigated in the system as tested and documented.

SPECpower_ssj.props input.loca_level.number_warehouses set to 112 due to a known inconsistency in processor reporting with this Java version.

.

See the Host Performance Report for additional details.

See the Host Performance Report for additional details.

See the Host Performance Report for additional details.

See the Host Performance Report for additional details.

SPECpower_ssj2008 Reporter Version: [SSJ 1.2.10, May 9, 2012]
