Fujitsu PRIMERGY TX100 S3p (Intel Xeon E3-1240V2) ssj_ops@100% = 467,481
ssj_ops@100% per JVM = 116,870
Test Sponsor: Fujitsu SPEC License #: 19 Test Method: Single Node
Tested By: Fujitsu Test Location: Paderborn, NRW, Germany Test Date: Jul 24, 2012
Hardware Availability: Aug-2012 Software Availability: Feb-2012 Publication: Aug 22, 2012
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     467,596
Calibration 2     467,123
Calibration 3     467,862
ssj_ops@calibrated=467,492
100% 100.0% 467,492 467,481
90% 90.9% 420,743 424,747
80% 80.3% 373,994 375,400
70% 70.0% 327,245 327,257
60% 60.2% 280,495 281,359
50% 50.1% 233,746 234,401
40% 40.3% 186,997 188,429
30% 30.2% 140,248 141,085
20% 20.0% 93,498 93,414
10% 9.8% 46,749 46,010
Active Idle   0 0
Graph of results
System Under Test
Set: 'TX100 S3p'
Set Identifier: TX100 S3p
Set Description: System Under Test
# of Identical Nodes: 1
Comment: Single Node
Hardware
Hardware Vendor: Fujitsu
Model: PRIMERGY TX100 S3p (Intel Xeon E3-1240V2)
Form Factor: Tower
CPU Name: Intel Xeon E3-1240V2
CPU Characteristics: Quad-Core, 3.40GHz, 8MB L3 Cache (Turbo Boost Technology up to 3.80 GHz)
CPU Frequency (MHz): 3400
CPU(s) Enabled: 4 cores, 1 chip, 4 cores/chip
Hardware Threads: 8 (2 / core)
CPU(s) Orderable: 1 chip
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 256 KB I+D on chip per core
Tertiary Cache: 8 MB I+D on chip per chip
Other Cache: None
Memory Amount (GB): 8
# and size of DIMM: 2 x 4096 MB
Memory Details: 4GB 2Rx8 PC3L-12800E ECC CL11; slots 1A, 1B populated
Power Supply Quantity and Rating (W): 1 x 250
Power Supply Details: Fujitsu Technology Solutions S26113-E565-V70-01
Disk Drive: 1 x 250GB, HDD, 3.5" SATA, S26361-F3701-E250
Disk Controller: Integrated SATA Controller
# and type of Network Interface Cards (NICs) Installed: 1 x Intel 82574L and 1 x Intel 82579LM Gigabit Network Connection (onboard)
NICs Enabled in Firmware / OS / Connected: 1/1/1
Network Speed (Mbit): 1000
Keyboard: None
Mouse: None
Monitor: None
Optical Drives: No
Other Hardware: None
Software
Power Management: Enabled ("Fujitsu Enhanced Power Settings" power plan)
Operating System (OS): Microsoft Windows Server 2008 R2 Enterprise with SP1
OS Version: Version 6.1.7601 Service Pack 1 Build 7601
Filesystem: NTFS
JVM Vendor: Oracle Corporation
JVM Version: Oracle Java HotSpot(TM) 64-Bit Server VM on Windows, version 1.6.0_31
JVM Command-line Options: -server -Xmx1024m -Xms1024m -Xmn853m -XX:ParallelGCThreads=2 -XX:SurvivorRatio=60 -XX:TargetSurvivorRatio=90 -XX:InlineSmallCode=3900 -XX:MaxInlineSize=270 -XX:FreqInlineSize=2500 -XX:AllocatePrefetchDistance=256 -XX:AllocatePrefetchLines=4 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15 -XX:LoopUnrollLimit=45 -XX:+UseCompressedStrings -XX:+AggressiveOpts -XX:+UseLargePages -XX:+UseParallelOldGC
JVM Affinity: start /affinity [0x03,0x0C,0x30,0xC0]
JVM Instances: 4
JVM Initial Heap (MB): 1024
JVM Maximum Heap (MB): 1024
JVM Address Bits: 64
Boot Firmware Version: R1.7.0
Management Firmware Version: None
Workload Version: SSJ 1.2.9
Director Location: Controller
Other Software: None
Boot Firmware Settings
Management Firmware Settings
None
System Under Test Notes
Notes
SPECpower_ssj.props input.load_level.number_warehouses set to 8 due to a known inconsistency in processor reporting with this Java version.
JVM Instance Summary
JVM Instance ssj_ops@100%
WIN-RPMHJC10L3A.001 116,727
WIN-RPMHJC10L3A.002 117,832
WIN-RPMHJC10L3A.003 116,785
WIN-RPMHJC10L3A.004 116,137
ssj_ops@100% 467,481
ssj_ops@100% per JVM 116,870
Graph of per-instance results
JVM 'WIN-RPMHJC10L3A.001' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     116,852
Calibration 2     116,833
Calibration 3     116,774
ssj_ops@calibrated=116,804
100% 99.9% 116,804 116,727
90% 91.9% 105,123 107,356
80% 80.3% 93,443 93,837
70% 69.9% 81,762 81,618
60% 59.8% 70,082 69,806
50% 49.7% 58,402 57,993
40% 40.4% 46,721 47,175
30% 30.0% 35,041 35,032
20% 20.2% 23,361 23,612
10% 9.5% 11,680 11,104
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-RPMHJC10L3A.002' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     117,747
Calibration 2     117,728
Calibration 3     118,063
ssj_ops@calibrated=117,895
100% 99.9% 117,895 117,832
90% 91.1% 106,106 107,383
80% 79.4% 94,316 93,563
70% 70.5% 82,527 83,087
60% 61.1% 70,737 72,065
50% 50.4% 58,948 59,411
40% 39.6% 47,158 46,711
30% 30.0% 35,369 35,362
20% 20.4% 23,579 24,062
10% 10.0% 11,790 11,829
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-RPMHJC10L3A.003' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     117,359
Calibration 2     117,168
Calibration 3     116,589
ssj_ops@calibrated=116,878
100% 99.9% 116,878 116,785
90% 89.9% 105,191 105,043
80% 80.2% 93,503 93,784
70% 69.9% 81,815 81,753
60% 59.5% 70,127 69,519
50% 50.3% 58,439 58,825
40% 40.8% 46,751 47,660
30% 30.4% 35,064 35,474
20% 19.8% 23,376 23,098
10% 9.9% 11,688 11,557
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-RPMHJC10L3A.004' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     115,638
Calibration 2     115,395
Calibration 3     116,436
ssj_ops@calibrated=115,915
100% 100.2% 115,915 116,137
90% 90.6% 104,324 104,966
80% 81.3% 92,732 94,217
70% 69.7% 81,141 80,800
60% 60.4% 69,549 69,969
50% 50.2% 57,958 58,172
40% 40.4% 46,366 46,882
30% 30.4% 34,775 35,217
20% 19.5% 23,183 22,641
10% 9.9% 11,592 11,521
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
