| Availability Dates |
|---|
| Hardware | Nov-98 |
| HTTP Software | Mar-99 |
| Operating System | Mar-99 |
| Hardware |
|---|
| Vendor | IBM Corporation |
| Model | S/390 9672-Y16 G5 |
| Processor | 500 MHz S/390 G5 CMOS |
| # of Processors | 1 |
| Primary Cache | 256KB L1 Cache |
| Secondary Cache | 4MB L2 Cache |
| Other Cache | None |
| Memory | 2GB Central Storage; 10GB Expanded Storage |
| Disk Subsystem | 1 9393-T82 RAMAC Virtual Array |
| Disk Controllers | 4 Integrated Virtual Control Units |
| Other Hardware | None |
| Software |
|---|
| Operating System | OS/390 V2R7 |
| File System Type | HFS (Hierarchical File System) |
| Other Software | |
| HTTP Software |
|---|
| Vendor | IBM Corporation |
| HTTP Software | IBM HTTP Server V5.1 for OS/390 |
| # of "threads" | 40 |
| Server Cache | Integrated |
| Log Mode | Common |
|
| Test Sponsor |
|---|
| Test Date | Nov-98 |
| Tested By | IBM - Raleigh |
| SPEC License | 11 |
| Network |
|---|
| # of Controllers | 7 |
| Network Controllers | ESCON Channels |
| # of Nets | 7 |
| Type of Nets | ESCON Channels |
| Network Speed | 136 Mbits/sec |
| MSL (sec) | 30 (Non RFC1122) |
| Time-Wait (sec) | 60 (Non RFC1122) |
| Load Generators |
|---|
| # of Load Generators | 7 |
| # of Processes Each | 40 |
| Model | IBM SP/6000 - 7015-R50 |
| Processor | 200 MHz 604e |
| # of Processors | 8 |
| Memory | 1.5GB |
| Network Controller | ESCON MCA Channel Adapters |
| Operating System | AIX 4.3.1 |
| Compiler | IBM Cset++ 3.1.3 |
| Benchmark Configuration |
|---|
| Maximum Requested Load | 3240 |
| Maximum Fileset Size (MB) | 1244 |
|
