| Availability Dates |
|---|
| Hardware | Oct-97 |
| HTTP Software | Mar-97 |
| Operating System | Dec-97 |
| Hardware |
|---|
| Vendor | IBM |
| Model | Netfinity 7000 |
| Processor | 200MHz Pentium Pro |
| # of Processors | 2 |
| Primary Cache | 8KBI+8KBD on chip |
| Secondary Cache | 1MB(I+D) |
| Other Cache | None |
| Memory | 2GB |
| Disk Subsystem | 1 4.51GB 7200RPM & 5-4.2GB 10K RPM drives |
| Disk Controllers | 2 7880 Ultra SCSI |
| Other Hardware | None |
| Software |
|---|
| Operating System | Windows NT Server 4.0 |
| File System Type | NTFS |
| Other Software | None |
| HTTP Software |
|---|
| Vendor | Microsoft |
| HTTP Software | Internet Information Server 3.0 |
| # of "threads" | 1 |
| Server Cache | Default |
| Log Mode | Standard |
|
| Test Sponsor |
|---|
| Test Date | May-98 |
| Tested By | IBM |
| SPEC License | 2 |
| Network |
|---|
| # of Controllers | 4 |
| Network Controllers | SysKonnect SK-NET FDDI-LP DAS |
| # of Nets | 4 |
| Type of Nets | FDDI DAS |
| Network Speed | 100Mb/s |
| MSL (sec) | 30 (Non RFC1122) |
| Time-Wait (sec) | 60 (Non RFC1122) |
| Load Generators |
|---|
| # of Load Generators | 8 |
| # of Processes Each | 3 |
| Model | Netfinity 3500 |
| Processor | 333MHz PentiumII |
| # of Processors | 2 |
| Memory | 64MB |
| Network Controller | SysKonnect SK-NET FDDI-LP DAS |
| Operating System | Windows NT Workstation 4.0 +SP3 |
| Compiler | |
| Benchmark Configuration |
|---|
| Maximum Requested Load | 1600 |
| Maximum Fileset Size (MB) | 873 |
|
