| Server Configuration and Availability |
|---|
| Vendor | Procom Technology Inc. |
| Hardware Available | May 2003 |
| Software Available | June 2003 |
| Date Tested | May 2003 |
| SFS License Number | 80 |
| Licensee Locations | Irvine, CA |
| CPU, Memory and Power |
|---|
| Model Name | NetFORCE 4100 |
| Processor | 3.06GHz Xeon (533 MHz Front_side Bus) |
| # of Processors | 1 |
| Primary Cache | (12KBI + 8KBD) on chip |
| Secondary Cache | 512KB |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | Brocade SilkWorm 3200 switch |
| Memory Size | 4 GB (system Memory) |
| NVRAM Size | 4 GB (RAID controller) |
| NVRAM Type | SDRAM Cache Memory |
| NVRAM Description | 3-days battery Protection |
| Server Software |
|---|
| OS Name and Version | NetFORCE Ver.4.2 |
| Other Software | None |
| File System | sfs2 |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Default |
| # NFS Processes | 70 |
| Fileset Size | 176.0 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | Gigabit Ethernet [PCI,1000Base-SX] |
| Number Networks | 1 |
| Number Network Controllers | 1 |
| Protocol Type | TCP |
| Switch Type | Extreme Summit48i |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 2 [Dual ports] |
| Number of Disks | 115 |
| Number of Filesystems | 7 |
| File System Creation Ops | N/A |
| File System Config | 23 RAID0 group of five disks each. |
| Disk Controller | Integrated 2Gb Fibre Channel |
| # of Controller Type | 2 [Model No: BA03052] |
| Number of Disks | 115 |
| Disk Type | Seagate ST3146807FC 146GB 10K RPM & ST336704FC 36GB 10K RPM |
| File Systems on Disks | Filesystem (vol1 vol2 vol3 vol4 vol5 vol6 vol7) |
| Special Config Notes | See notes below. |
|
