| Name | Dell Inc. PowerEdge |
| Vendor | Dell Inc. |
| Vendor URL | http://dell.com/ |
| Available | May-2018 |
| Model | R840 |
| Form Factor | 2U Rack. |
| CPU Name | Intel Xeon Platinum 8180 |
| CPU Characteristics | 28 core, 2.50GHz, 38.5MB L3 Cache (Turbo Boost Technology up to 3.80 GHz) |
| Number of Systems | 1 |
| Nodes Per System | 1 |
| Chips Per System | 4 |
| Cores Per System | 112 |
| Cores Per Chip | 28 |
| Threads Per System | 224 |
| Threads Per Core | 2 |
| Version | 1.1.1 |
| CPU Frequency (MHz) | 2500 |
| Primary Cache | 32KB(I)+32KB(D) per core |
| Secondary Cache | 1 MB (I+D) per core |
| Tertiary Cache | 38.5MB (I+D) on chip per chip |
| Other Cache | None |
| Disk | 1 x 960 GB SATA SSD |
| File System | xfs |
| Memory Amount (GB) | 1536 |
| # and size of DIMM(s) | 48 x 32GB |
| Memory Details | 2Rx4 PC4-2666V-R; slots A1-12, B1-12, C1-12, D1-12 populated |
| # and type of Network Interface Cards (NICs) | 4 x 1 Gbit NICs |
| Power Supply Quantity and Rating (W) | 2 x 1100W |
| Other Hardware | None |
| Cabinet/Housing/Enclosure | None |
| Shared Description | None |
| Shared Comment | None |
| Notes | - Yes: The test sponsor attests, as of date of publication, that CVE-2017-5754 (Meltdown) is mitigated in the system as tested and documented
- Yes: The test sponsor attests, as of date of publication, that CVE-2017-5753 (Spectre variant 1) is mitigated in the system as tested and documented
- Yes: The test sponsor attests, as of date of publication, that CVE-2017-5715 (Spectre variant 2) is mitigated in the system as tested and documented
|
|
|
