SPECjbb2015 Report for jbb2015-20171108-00272 : 14262 max-jOPS ; 5708 critical-jOPS

Hardware hw_1
Name	K1411ID
Vendor	KTNF
Vendor URL	http://ktnf.co.kr/
Available	Nov-2017
Model	K1411ID
Form Factor	1U
CPU Name	Intel Xeon E3-1270v6
CPU Characteristics	4core, 3.80 GHz, 8MB L3 Cache (Turbo Boost Technology up to 4.20 GHz)
Number of Systems	1
Nodes Per System	1
Chips Per System	1
Cores Per System	1
Cores Per Chip	4
Threads Per System	8
Threads Per Core	2
Version	None
CPU Frequency (MHz)	3800
Primary Cache	32KB+32KB per core
Secondary Cache	256KB per core
Tertiary Cache	8MB on chip per chip
Other Cache	None
Disk	1 x 480 GB SSD SATA
File System	BTRFS
Memory Amount (GB)	32GB
# and size of DIMM(s)	4 x 8GB
Memory Details	DDR4 U-dimm 8GB 2133MHz
# and type of Network Interface Cards (NICs)	2 x 1 Gbit NICs
Power Supply Quantity and Rating (W)	2 x 450W
Other Hardware	None
Cabinet/Housing/Enclosure	None
Shared Description	None
Shared Comment	None
Notes	None
Other Hardware network_1
Name	None
Vendor	None
Vendor URL	None
Version	None
Available	None
Bitness	None
Notes	None

Operating System os_1
Name	SUSE Linux Enterprise Server 12 SP2
Vendor	SUSE
Vendor URL	http://www.suse.com
Version	4.4.21-69-default
Available	Oct-2016
Bitness	64
Notes	None
Java Virtual Machine jvm_1
Name	Oracle Java SE 8u151
Vendor	Oracle Corporation
Vendor URL	http://www.oracle.com
Version	Java HotSpot 64-Bit Server VM, version 1.8.0_151
Available	Oct-2017
Bitness	64
Notes	None
Other Software other_1
Name	None
Vendor	None
Vendor URL	None
Version	None
Available	None
Bitness	None
Notes	None

SUT
- Hardware config_1
  - OS Image os_Image_1
    - JVM jvm_Composite_1 : Composite

Hardware
OS Images	os_Image_1(1)
Hardware Description	hw_1
Number of Systems	1
SW Environment	non-virtual
Tuning	BIOS Configuration CPU Power and Performance Policy set to Performance
Notes	None

OS Image os_Image_1
JVM Instances	jvm_Composite_1(1)
OS Image Description	os_1
Tuning	None
Notes	None
JVM Instance jvm_Composite_1
Parts of Benchmark	Composite
JVM Instance Description	jvm_1
Command Line	-server -Xms25g -Xmx25g -Xmn22g -XX:+AggressiveOpts -XX:+UseLargePages -XX:LargePageSizeInBytes=2m -XX:+UseParallelGC -XX:+UseNUMA -XX:+AlwaysPreTouch
Tuning	None
Notes	None

max-jOPS = jOPS passed before the First Failure
Pass/Fail	Pass	Pass	Fail	Fail	Fail
jOPS	14096	14262	14428	14594	14760

critical-jOPS = Geomean ( jOPS @ 10000; 25000; 50000; 75000; 100000; SLAs )
Response time percentile is 99-th
SLA (us)	10000	25000	50000	75000	100000	Geomean
jOPS	2405	5030	6844	8043	9102	5708

Note

(Actual % in the Mix - Expected % in the Mix) must be within:

'Main Tx' limit of +/-5.0% for the requests whose expected % in the mix is >= 10.0%

'Minor Tx' limit of +/-1.0% for the requests whose expected % in the mix is < 10.0%

There were no non-critical failures in Response Time curve building

This section lists properties only set by user

User did not set any property for this run


Level: COMPLIANCE
Check	Agent	Result
Check properties on compliance	All	PASSED

High-bound (max attempted) is 16584 IR

High-bound (settled) is 15378 IR

SPECjbb2015 Version: [SPECjbb2015 1.00, June 24, 2015]

KTNF K1411ID	14262 SPECjbb2015-Composite max-jOPS 5708 SPECjbb2015-Composite critical-jOPS
Tested by: Telecommunications Technology Association	Test Sponsor: Telecommunications Technology Association	Test location: Seongnam-city, Gyeonggi-do, Korea	Test date: Nov 7, 2017
SPEC license #: A83	Hardware Availability: Nov-2017	Software Availability: Oct-2017	Publication: Mon Nov 27 16:11:42 EST 2017


SPECjbb2015-Composite: Single JVM/Single Host (# of groups: 1) Overall SUT Description SUT Description max-jOPS and critical-jOPS Details Number of probes Request Mix Accuracy Rate Of Non-Critical Failures Delay between performance status pings IR/PR Accuracy Topology SUT Configuration Properties Validation Details Link to Full Disclosure	Overall Throughput RT curve
