Advanced Visualizer Viewset (AWadvs-03)



Advanced Visualizer from Alias/Wavefront is an integrated workstation-based 3D animation system that offers a comprehensive set of tools for 3D modeling, animation, rendering, image composition, and video output.

The Advanced Visualizer provides:

For more information on Advanced Visualizer, please visit the Alias/Wavefront Advanced Visualizer web page.

All operations within Advanced Visualizer are performed in immediate mode with double buffered windows. There are four basic modes of operation within Advanced Visualizer:

These are the 10 tests specified by the viewset that represent the most common operations performed by Advanced Visualizer:

Test

Weight

Advanced Visualizer functionality represented

1

41.8%

Material shading of polygonal animation model with highest interactive image fidelity and perspective projection.

2

28.5%

Wireframe rendering of polygonal animation model with perspective projection.

3

10.45%

Material shading of polygonal animation model with lowest interactive image fidelity and perspective projection.

4

9.5%

Smooth shading of polygonal animation model with perspective projection.

5

4.75%

Flat shading of polygonal animation model with perspective projection.

6

2.2%

Material shading of polygonal animation model with highest interactive image fidelity and orthogonal projection.

7

1.5%

Wireframe rendering of polygonal animation model with orthogonal projection.

8

.55%

Material shading of polygonal animation model with lowest interactive image fidelity and orthogonal projection.

9

.5%

Smooth shading of polygonal animation model with orthogonal projection.

10

.25%

Flat shading of polygonal animation model with orthogonal projection.

Test #

Weight (%)

Testing Parameters (Also see default parameters)

1

41.8%

-pg DYN -rm POLYGON -cp FRAME -zb -nll 2 -bf -tx advs1.mtv -magf LINEAR -minf LINEAR_MIPMAP_LINEAR -te MODULATE -xws 720 -yws 720

2

28.5%

-pg DYN -rm LINE -cp FRAME -xws 720 -yws 720

3

10.45%

-pg DYN -rm POLYGON -cp FRAME -zb -nll 2 -bf -tx advs2.mtv -te MODULATE -xws 720 -yws 720

4

9.5%

-pg DYN -rm POLYGON -cp FRAME -zb -nll 2 -bf -xws 720 -yws 720

5

4.75%

-pg DYN -rm POLYGON -cp FRAME -zb -f -nll 2 -bf -xws 720 -yws 720

6

2.2%

-pg DYN -rm POLYGON -cp FRAME -zb -nll 2 -or -bf -tx advs1.mtv -magf LINEAR -minf LINEAR_MIPMAP_LINEAR -te MODULATE -xws 720 -yws 720

7

1.5%

-pg DYN -rm LINE -cp FRAME -or -xws 720 -yws 720

8

.55%

-pg DYN -rm POLYGON -cp FRAME -zb -nll 2 -or -bf -tx advs2.mtv -te MODULATE -xws 720 -yws 720

9

.5%

-pg DYN -rm POLYGON -cp FRAME -zb -nll 2 -or -bf -xws 720 -yws 720

10

.25%

-pg DYN -rm POLYGON -cp FRAME -zb -f -nll 2 -or -bf -xws 720 -yws 720
